Description
Highline:
1. Multiple installations and applications
2. Airway pressure gauge and safety valve, more safe
3. Selectatec vaporizer，easy to assemble
4. Independent ACGO switch，one-step switching
5. Pre-calibrated APL valve，easy to set the pressure limit
6. CO2 absorber canister with large capacity, lever lock design
|
Specifications |
||
|
Dimensions |
Anesthesia Machine (without stand) :H 385mm，W 405mm，L 265mm Anesthesia Machine (with stand) : H 1230mm，W535mm，L575mm |
|
|
Weight |
≤10kg (not including stand, vaporizer and other accessories) ≤14kg (include vaporizer, not include stand and other accessories) ≤22kg (include stand vaporizer and other accessories) |
|
|
Max Load on Top |
10kg |
|
|
Handle |
Single handle, located in the middle of the top |
|
|
Trolley |
||
|
Dimensions |
H 850mm，W 535mm，L 575mm |
|
|
Weight |
8kg |
|
|
Caster |
4 piece, with brake |
|
|
Gas filter canister Holder |
Standard Outfit |
|
|
Specifications of Gas Circuit System |
||
|
Source Gas |
Oxygen |
|
|
Air Source Pressure Range |
280-600kpa/40-87psi |
|
|
Port Type |
NIST |
|
|
Air Source Pressure Gauge |
0-1Mpa/0-140psi |
|
|
Specifications of Gas Circuit System |
|
|
Air Source Safety Valve |
Built-in |
|
Flowmeter Adjustment Range |
0-4L/min(single tube oxygen flowmeter) |
|
Vaporizer Base |
Single tank position，Selectatec |
|
Respiratory System Specifications |
|
|
Breathing Bag Connector |
22mm(OD) / 15mm(ID) |
|
Inhale Port |
22mm(OD)/15mm(ID) |
|
Exhale Port |
22mm(OD) / 15mm(ID) |
|
ACGO Port |
22mm(OD)/15mm(ID) |
|
AGSS Port |
30mm (OD) |
|
Airway Pressure Gauge |
-20cmH2O~100cmH2O |
|
APL Valve |
Adjustment Range：0~70cmH2O，with one key closing button |
|
CO2 Absorber Canister |
Volume 1400ml |
